Gasoline Engine Water Pump

Agricultural Gasoline Engine Water Pump

Description: Agricultural Gasoline Engine Water Pump.
INQUIRY EMAIL

Agricultural Gasoline Engine Water Pump:

Powerful and stable: gasoline engine water pumps utilize gasoline engines as their power source, boasting high power and stable performance, enabling them to meet various pumping needs.
Portable and convenient: gasoline engine water pumps are typically designed with a trolley structure, which is compact and lightweight, making them easy to operate and carry. This design allows for their use in various complex environments and locations.
Versatile applications: This type of water pump is not only suitable for conventional uses such as agricultural irrigation and water supply for construction sites, but also plays a crucial role in emergency firefighting and urban environmental protection, demonstrating a wide range of applications.

Product Parameters：

Model	139-10E	142-15E	170-20E	170-30E	170-40E	192-60E	80-80E
Inlet and outlet diameter (mm)	25(1 inches)	40(15 inches)	50(2 inches)	80(3 inches)	100(4 inches)	150(6 inches)	200(8 inches)
Rated maximum flow rate (m³/h)	5/9	10/15	20/30	30/60	40/80	140/180	200/398
Head (m) rated/maximum	15/28	15/28	15/30	15/40	16/30	14/20	10/20
Suction lift (m) rated/maximum	7	7	7	7	7	7	7
Self-priming time (S)	≤180S	≤180S	≤180S	≤180S	≤180S	≤180S	≤180S
Rotation speed (r/min)	3600	3600	3600	3600	3600	3600	3600
Startup mode	Manual start	Manual start	Manual start / Electric start	Manual start / Electric start	Manual start / Electric start	Manual start / Electric start	Manual start / Electric start
Matched engine model	170F	170F	170F	170F	170F	192F	2V80
Displacement (ml)			212	212	212	440	750
Rated power (kW)	4.8	4.8	5.5	5.5	5.5	8.5	21.0
Rated rotation speed (r/min)	6500	6500	3600	3600	3600	3600	3600
Engine oil capacity (L)	0.2	0.2	0.7	0.7	0.7	1.1	1.5
Fuel capacity (L)	1.5	1.5	3.6	3.6	3.6	7	35
