Water Well Borehole Drilling Rig--DH180

Track-Type Water Well Drilling Rig

Description: HT is a professional manufacturer for track-type water well drill rig.
INQUIRY EMAIL

Track-Type Water Well Drilling Rig:

HT is a professional manufacturer for track-type water well drilling rig equipment.

Full hydraulic water well drilling equipment, hydraulic transmission:

700Nm is torque at the rotation speed of 150r/min, torque is in proportion to the rotation speed, if the rotation speed adjusted to 60-70r/min,its torque can become double.

Compared with old models such as HZ rig :
HZ rig uses mechanical transmission whose hydraulic cylinder stroke is only 45cm,our rig uses hydraulic transmission whose hydraulic cylinder stroke is 2m,for a 2m length pipe,our rig only needs one time for hydraulic pressure adding to press it down,but HZ rig needs 4-5 times for hydraulic pressure adding to press it down (labor intensity is big, operation is complicated)

Water Well Drilling Rig:

Model	DH180	DH200
Full Hydraulic Working Way	single hydraulic system	two hydraulic systems
Max Drilling Depth	180m	210m
Max Drilling Diameter	450mm	500 mm
Max Torque	700 Nm	900 Nm
Max Lifting Force	50 Kn	100 Kn
Power Source	diesel engine powered
Main Machine Power	25 Hp
Rotation Speed	0-150 r/min (Continuously Variable Transmission)
